Key Features
• Lens diameter: 125mm
• 1 Color wheel: 6 colors + open, rainbow effect
• 1 Fixed gobo wheel: 6 gobos + open ci• Prisms: 1 fixed tower prism / 1 rotatable 8-facet prism; rotation and overlay of tower and 8-facet prisms
• Interchangeable multicolor effect and fixed tower prism
• Excellent color effects
• 0-100% smooth dimming
• Variable strobe speeds
Technical Specifications
• Light source: 7R 230W (2,000 hours)
• Color temperature: 7800K
• Beam angle: 1.8°
• Channel mode: 16CH
• Control protocols: DMX512, RDM
• Pan/Tilt: 540° / 270°
• Precision: 16-bit scanning accuracy
• Correction: Automatic position correction for Pan/Tilt
• Display: LCD display
• Signal I/O: 3-pin XLR connectors
• Power I/O: Power connector input/output
• IP rating: IP20
Physical Parameters
• Input power: 100-260V~ 50/60Hz
• Power consumption: 300W
• Dimensions: 268 x 220 x 454mm
• Carton dimensions: 350 x 370 x 480mm
• Flight case: 490 x 310 x 600mm (2-in-1)
