1. Wide voltage range: AC90V-235V, 50-60Hz
2. Wide-voltage power supply: 400W
3. Light source: 230W (domestic)
4. Color temperature: 8000K
5. Color system: Color wheel with 13 colors + rainbow effect
6. Gobo system: Gobo wheel with 13 fixed gobos + 1 open (white)
7. Focus system: Electronic focus
8. Strobe: 0.5–20 flashes/second, adjustable speed
9. Motors: 3-phase motors for X and Y axes ensure stable speed control and precise positioning
10. Dimming curve: 0%–100% linear dimming; smooth and flicker-free
11. Beam angle: 2–5°
12. DMX channels: 16 or 20 channels
13. Lens diameter: 152mm
14. Waterproof rating: IP55
15. Control modes: DMX512, Auto-run, Master-Slave, RDM; supports remote DMX addressing via large-scale controllers
16. Prism system: 8-facet prism and (8+16)-facet prism (prism configuration customizable upon request)
17. Display: LCD screen; rotatable 180° to suit various installation positions
18. Pan/Tilt: High-precision 3-phase motors; accurate positioning, smooth operation, and automatic position correction
19. Pan: 540° rotation; 8/16-bit resolution; fine-tuning capability
20. Tilt: 270° rotation; 8/16-bit resolution; fine-tuning capability
21. Cooling system: Efficient heat dissipation design to rapidly dissipate internal heat; extends light source lifespan and delays lumen depreciation; low-noise fan system with excellent drive performance and ultra-quiet operation 22. Installation method: Upright or inverted (hanging)
23. Fixture dimensions: 35.7 x 36 x 61.9 cm; Carton dimensions: 47.5 x 44.5 x 68 cm; Net weight: 24 kg; Gross weight: 28 kg
A Masterpiece of Craftsmanship: Featuring a premium design and immense power, this waterproof beam light—capable of projecting a thick, robust beam—sets a high standard for optical performance, structural integrity, and aesthetics. It utilizes a state-of-the-art, high-brightness light source, advanced optics, and rigorous industrial design to ensure a flawless lighting performance.
