Product Specifications
Input Voltage: AC 90V–240V / 50Hz–60Hz
Light Source: 600W LED module
Light Source Lifespan: 20,000 hours
Rated Power: 650W
Channel Modes: 23 channels / 25 channels
Pan: 540° (16-bit precision scanning) with electronic error correction
Tilt: 270° (16-bit precision scanning) with electronic error correction
Dimming System: 0–100% linear adjustment
Focusing System: Linear adjustment from 4m to 50m
Frost System: 1 independent frost effect; produces a soft, natural beam
Zoom Angle: 4°–35°
High-Speed Strobe: 0–30 flashes/second; adjustable speed
Colors: 8 colors + open (white)
Color Mixing System: Linear CMYK + CTO color mixing system
Fixed Gobos: 12 fixed gobos + open
Rotating Gobos: 7 glass gobos + open; each glass gobo supports independent forward/reverse rotation
Prism System: One 8-facet prism and one 6-facet linear prism; each prism can move independently (in/out)
Control Modes: Console reset function, auto-run mode, master-slave mode
Display: 2.8-inch touchscreen + button controls; bilingual (Chinese/English) OS; 180° display flip function
Optics: Composite optical lens assembly
Control Signal: International standard DMX512 with RDM support; supports online software upgrades and manual address setting
Cooling System: Axial fan-assisted cooling
Operating Environment: -20°C to 40°C
Protection Rating: IP20
Signal Cables: Input with 3-pin XLR connector; output with 3-pin XLR socket
Power Cables: Aviation-style connectors for input and output
Net Weight: 22.9 kg
Dimensions: 38 x 27 x 67 cm
Carton Dimensions: 63 x 53 x 51 cm (per unit)
Carton Weight: 26.5 kg Flight case packaging dimensions: 75 x 46 x 87 cm (2 units)
Flight case packaging weight: 76 kg (2 units)
