1. Wide voltage range: AC 90V–235V, 50–60Hz
2. Wide-voltage power supply: 650W
3. Light source system: 371W (Osram)
4. Color temperature: 7900 ± 500K
5. Color system: Color wheel with 14 colors + open (white)
6. Gobo system: Gobo wheel with 17 fixed gobos + open (white)
7. Focus system: Electronic focus
8. Frost: Frost function included; capable of producing a soft-light effect
9. Strobe: Dual-motor independent strobe effect; 0.5–20 flashes/sec, adjustable speed
10. Motors: 3-phase motors for X and Y axes ensure stable speed (fast/slow) and precise positioning
11. Dimming curve: 0%–100% linear dimming; smooth and flicker-free
12. Beam angle: 0–2°
13. DMX channels: 16 or 20 channels
14. Lens diameter: 165mm
15. Waterproof rating: IP66
16. Control modes: DMX512, Auto-run, Master-Slave, RDM; supports remote DMX addressing via large-scale controllers
17. Prism system: 8-facet prism and (8+16)-facet prism (prism configuration customizable upon request)
18. Display: LCD screen; rotatable 180° to suit various installation positions
19. Pan/Tilt: High-precision 3-phase motors; accurate positioning, smooth operation, and automatic position correction
20. Pan: 540° rotation; 8/16-bit resolution; includes fine-tuning
21. Tilt: 270° rotation; 8/16-bit resolution; includes fine-tuning 22. Cooling System: Features a combination of fixture body heat dissipation and an intelligent fan-assisted airflow system. Software-based thermal flow analysis optimizes air convection to rapidly dissipate internal heat, thereby delaying light source degradation and extending bulb lifespan. The low-noise cooling fan system offers superior drive performance and operates with minimal noise.
23. Housing: Cast aluminum and outdoor-grade engineering plastic.
24. Mounting: Upright or inverted (hanging) installation.
25. Fixture Dimensions: 43 x 26 x 63 cm.
Net Weight: 25 kg; Gross Weight: 29 kg.
A Masterpiece of Craftsmanship: Combining a premium appearance with immense power, this waterproof beam light—featuring a robust, thick beam—sets high standards for optical performance, structural integrity, and aesthetics. It integrates a state-of-the-art, high-brightness light source with advanced optics and rigorous industrial design to ensure a flawless lighting performance.
